Technical Parameter
| Dimensions | L86xW86xH29(mm) |
| Standard Structure | 304 stainless steel panel and button |
| Current Rating | 3A@36VDC MAX |
| Output Contact | NO/NC/COM |
| Mechanical Life | 100000 tests |
| Suitable for Door | Hollow Door |
| Operating temp | -10～+55℃(14-131F) |
| Operating Humidity | 0-95% (relative humidity) |
| Panel Material | 304 stainless steel panel with wiredrawing finish |
| Weight | 0.2kg |
| Certificate | CE-EMC CE-LVD FCC-VOC RoHS REACH WEEE |
Advantage
Dimension Diagram
